Product name:  Pneumatic liposome extruder (experimental pilot production type)

Product model:  GExtruder-10ml;GExtruder-100ml; GExtruder-800ml;GExtruder-3000ml

Product Exhibitor:  Genizer

Product Origin:  United States

Product specifications: Gextruder-10mL; Gextruder-100mL; Gextruder-1000mL; Gextruder-2000mL

Product characteristics:

Genizer Jacketed Liposome Extruders is compressed air driven, temperature controlled, from testing to manufacture production of liquid and lipoplex for drug and gene delivery.

Brief introduction:

The pneumatic sandwich liposome extruder can be used to prepare liposomes or lipid microspheres with specific particle sizes of 0- 5,000 ml. The Jacketed Liposome Extruders are designed to generate homogeneous unilamellar liposomes and Lipopolyplex. Extrusion is a one-step procedure that produces liposomes by forcing lipid suspensions of drug, protein or gene through track-etched filters with defined pore size. It is relatively gentle, exposing the formulation to moderate pressures up to 1,500 psi at controlled temperatures. The Genizer Extruder is easily cleaned and suitable for sterilization, compliance with FDA and GMP sanitary standards in Pharmaceuticals.

Liposome extruder schematic

Product parameters:

Liposome sample handling capacity 0ml-5000ml to

sample handling capacity 0ml

Cooling interlayer

pneumatic

sanitary grade micron perforated extrusion membrane support plate (no need to use Drain Disc or Filter Support)

Optional Liposome extrusion membrane 10nm, 30nm, 50nm, 80nm, 100 nm, 400nm, 800nm, 1000nm, 2μm, 5μm, 10μm, 20μm, 30μm and other

advantages:

It adopts a micron perforated extruded membrane support plate (regular holes visible to the naked eye) and has no metal particles. It is suitable for drug production and

use. It only needs to install 1 polycarbonate membrane. There is no need to install another Drain Disc or Filter Support. It is easier to operate and long-term use can save a lot of money to buy auxiliary membranes.

The power supply of the gas cylinder does not need to be pushed back and forth manually. It has a higher and wider sample processing volume range than manual extrusion instruments.

American Genizer jacketed pneumatic liposome extruder Chinese instructions.pdf
